BMW OPS working on cars with optical fiber,both diagnose and programming for BMW cars.Works with models from E65 on.DIS version for hard disk fit all laptops is V57,SSS is V37.
On vehicle models from the E65 on, BMW is for the first time using fibre-optic cables as standard for communication between control units.
The optical buses are notable for their high data transmission rate and they are not susceptible to electromagnetic interference. The optical buses in question are the MOST bus, primarily used for in-car entertainment electronics, and the byteflight bus, which serves predominantly safety-critical functions.
OPPS has been designed for encoding, individualising and programming ( CIP) via the Software Service Station (SSS) and envisaged for use as part of the BMW diagnostic system (DIS) from DISPlus and Group Tester One (GT1). It is intended for testing and programming tasks from the E65 series, taking the place of the diagnostic head.
OPS is intended for rapid programming of control units.
When operated at the SSS, no diagnostic or technical measuring pro-cedures are possible, as no measuring technology is incorporated; in this instance, OPPS / OPS is used predominantly for programming control units (flashing). Communication with the vehicle can be performed both via the MOST and via the OBD interface. The OBD interface is required for the power supply to the OPPS / OPS and has communication properties via which the vehicle can be identified and the data to be programmed can be determined. From CIP version 7.0, it is possible to delete fault code memories via OPPS / OPS.
OPS with DIS for diagnosis Supported Models:
Vehicle interface via OBD-II socket:
E87, E90, E91, E92, E60, E61, E63, E64, E65, E66, E70, E83, E85, E86, E38(OBD-II), E39(OBD-II ), E46(OBD-II ), E52, E53, R56, R50, R52, R53
OPS with SSS for programming Supported Models:
(1) Vehicle interface via OBD-II socket:
E87, E90, E91, E92, E60, E61, E63, E64, E65, E66, E70, E83, R56, R50, R52, R53
(2) MOST compatibility ( multichannel programming):
E87, E90, E91, E92, E60, E61, E63, E64, E65, E66, E70, R56, R50, R52, R53
1. OPS multiplexer(Orange Head)
2. OBD-II diagnostic cable
3. LAN cable
4. OPS MOST cable
5. Hard disk
Q: How to update this product?
A: This product update is through hard disk.You can send the old hard disk back to us and we install the new software in the hard disk and send back to you.You only have to pay the shipping cost for this update.
Q: What is the difference between OPS and OPPS?
A: This two product almose the same function.Compared with OPS,the quality of OPPS better.
Q: Does this BMW OPS support an old models like E36,E34 and E39?
A: You can download the car model that BMW OPS support from our website.It can works on E36 E34 E39.
QWhat is the advantage of hard disk fit all computers?
A:Hard disk is fit all laptops.The advantage is it do not have much demand on laptop,only require your laptop support USB 2.0. But this one software installation need pay a little bit attention.the installation maunal you can download from our website. The version for this hard disk is DIS V55 SSS V32.
Compared with T30 version hard disk,the hard disk fit IBM T30 speed may more fast and stable.We suggest this one to those who have IBM T30.
